Capacity: 200 - 800 kg. Suitable for outdoor use due to robust construction, from 500 kg. load capacity with high-speed gear for small loads and faster winding and unwinding of the unloaded rope.
Features:
- Compact aluminium housing and enclosed sprocket wheel drive. From a capacity of 500 kg with speed increasing ratio for small loads and quicker winding and unwinding of the unloaded rope.
- Spur gear drive for optimal efficiency and comfortable handling.
- Enclosed gear for the protection of parts inside, also for arduous applications.
- Low-friction shaft sliding bearings for improved rope lead-off and a longer service life of the winch.
- Wide rope drum for a large rope capacity with two rope attachment points.
- Easy and quick mounting.
- With integrated safety spring brake system and removable crank. The winches can be operated from either side.
- Material: Aluminium
- Marking: According to standard
- Standard: EN 13157
